The NS-208 is an 8-Port Industrial 10/100 Mbps Unmanaged Ethernet Switch, with DIN-Rail mounting. Offering fast, easy to use, and reliable LAN dispersion, the NS-208 is ideal in almost any setting! It has an MDI/MDIX function. It can connect 8 workstations and automatically switches the transmission speed (10 Mbps or 100 Mbps) for corresponding connections. The flow control mechanism is negotiated. There is link/data rate LEDs for each port to aid trouble-shooting. Port connectors are shielded RJ-45.

• Automatic MDI / MDI-X crossover for plug-and-play
• Each port supports both 10/100 Mbps speed auto negotiation
• Store-and-forward architecture
• Full duplex IEEE 802.3x and half duplex backpressure flow control
• 1.4 Gbps high performance memory bandwidth
• Integrated look up engine with dedicated 1K unicast MAC addresses
• Supports +10 ~ +30V DC voltage
• Supports operating temperatures from -30°C ~ +75°C
• DIN rail mount for industrial usage

• Compatibility: IEEE 802.3, IEEE802.3u, IEEE802.3x
• CE and FCC Certified
• Vibration Standard: IEC61373
• Electrical Standard: EN50155
• Interface: 10/100 Base-T
• Port: 10/100 Mbps x 8 (Shielded RJ-45 Jack)
• Provides LEDs for network and power monitoring
• ESD Protection:
• 8KV Contact Discharge
• 15KVAir-Gap Discharge
• Cables:
• 10 Base-T (Cat. 3, 4, 5 UTP cable; 100m Max.)
• 100 Base-T (Cat. 5 UTP cable; 100m Max.)
• Environment:
• Operating temperature: -30°C ~ +75°C
• Storage Temperature: -30°C ~ +85°C
• Relative Humidity: 10% to 90% non-condensing
• Power requirements: 10 to 30V DC (Removable Terminal Block)
• Low power consumption: 0.052A@24vdc, ± 5%, allowed
