ET-7005: 8 Channel Thermistor Input and 4 Channel Isolated Output Data Acquisition Ethernet I/O Module and Modbus TCP Protocol

ET-7005

E-mail this Product

Product Reference & Support :

FREE EZ Data Logger Software

Emergency Warning Systems Video

8 Channel Thermistor Input and 4 Channel Isolated Output Data Acquisition Ethernet I/O Module and Modbus TCP Protocol

Product Pricing:

ET-7005 : $459.00

Please Call 1-888-971-9888 for Volume and OEM discount pricing!

Features

The ET-7005 is a 16-bit, 8-channel Thermistor inputs and 4-channel digital outputs module that provides programmable input range on all analog channels and digital output can be set alarm output. Each analog channel is configurable for an individual range.

The ET-7005 is a web-based Ethernet I/O module that features a built-in web server which allows configuration, I/O monitoring and I/O control by using a regular web browser. Through the web HMI function, no programming or HTML skills are needed; creating dynamic and attractive web pages for I/O monitoring and I/O control is easy.

The ET-7005 offers easy and safe access for users from anytime and anywhere! ET-7005 also supports Modbus/TCP protocol that makes seamless integration to SCADA software.

Specifications & Additional Information

CPU
CPU	80186 CPU (80MHz)
SRAM	512K Bytes
Flash Memory	512K Bytes
EEPROM	16K Bytes
Dual Watchdog	Yes
Communication
Ethernet Port	10 / 100 Base-TX (With Link, Activity LED Indicator) Automatic MDI/MDI-X
Analog Input
Input Channels	8 Differential
Input Type	Precon ST-A3, Fenwell U, YSI L100, YSI L300, YSI L1000, YSI B2252, YSI B3000, YSI B5000, YSI B6000, YSI B10000, YSI H10000, YSI H30000, User-defined
Resolution	16-bit
Sampling Rate	8 samples/Sec. total
Accuracy	+/-0.1 % or better
Zero drift	+/-20 μV/°C
Span drift	+/-25 ppm/°C
Input Impedance	> 1M Ohms
Common Mode Rejection	86 dB min.
Normal Mode Rejection	100 dB
Open Wire Detection	Yes
Individual Channel Configuration	Yes
ESD Protection	4 kV Contact for each terminal, and 8KV Air for random point
EFT Protection	4 kV for Power
Digital Output
Output Channels	4 (Sink)
Input Type	Isolated Open Collector
Max Load Current	700 mA/Channel
Load Voltage	5 VDC ~ 50 VDC
2 Way Isolation
Ethernet	1500 V DC
AI and DO	2500 V DC
Mounting
Din Rail Mount	Yes
Wall Mount	Yes
LED Display
L1 LED	as Run indicator
L2 LED	as Link/Act indicator
L3 LED	as 10/100 M indicator
Power Requirements
Protection	Power reverse polarity protection
Required Supply Voltage	+10 VDC ~ 30VDC (non-regulated)
Power consumption	0.10 A/24 VDC
Environment
Operating Temperature	-25 °C ~ +75 °C
Storage Temperature	-30 °C ~ +80 °C
Relative Humidity	5 to 90% RH, non-condensing
Dimensions
Dimensions(W x L x H )	123 mm x 72 mm x 35 mm
